Tenda AC5 AC1200 Mbps Ethernet Dual-Band Wi-Fi Router

General

Brand

Tenda

Model

Tenda AC5

Router Type

Wireless & Ethernet

Part No

AC5

Hardware

Data Transfer Rate (Wifi)

1200 Mbps (300 + 867)

WiFi Network Standards

IEEE802.3, IEEE802.3u

LAN Network Standard

10/100

WAN Network Standard

10/100

Data Transfer Rate (Lan)

100 Mbps

CPU

1GHz

RAM

32MB

Interface

Interface(s)

1 x 10/100 RJ45 WAN, 3 x 10/100 RJ45 LAN

Number of WAN Port

1

Number of LAN Port

3

USB Interface

No

USB Interface Application

No

Internet Connectivity

WAN Only

SIM Card Slot Included

No

Sim Card Slot

No

Wireless

Antenna (Type & Qty)

4 x 6dBi External Antenna

WAN Type

PPPoE, Dynamic IP, Static IP, PPPoE(Russia), PPTP(Russia), L2TP(Russia), Unify, Maxis, Maxis-special, Celcom, Digi

Wi-Fi Generation

Wi-Fi 5

Band

Dual

Wi-Fi Coverage (Approximate)

Up to 2000 sq. ft.

Number of Concurrent User

Up to 25 User connections

Performance

3G/4G

No

Mesh Technology

No

MIMO Technology

Yes

Security

Operating Frequency

2.4 GHz, 5 GHz

Operation/Working Wireless Modes

Router Mode, AP Mode, Universal Repeater Mode (Client+AP,WISP)

Security Protocols

WPA2-PSK

Firewall Protocols

ICMP Flood Attack Defense, TCP Flood Attack Defense, UDP Flood Attack Defense, Block Ping From WAN

VPN Support

Yes

Voice Assistant

No

Built in Antivirus

No

Print Compatible

No

Electrical

Power

Input: 100-240V-50/60Hz 0.4A, Output: DC 9V1A

Operating Temperature

0 degree C - 40 degree C

Storing/Storage Temperature

-40 degree C - 70 degree C

Operating Humidity

10% - 90% non-condensing

Storing/Storage Humidity

5% - 90% non-condensing

Physical Description

Button

1 x Wi-Fi/ Reset button

LED Indicators

1 x SYS

Dimensions

200 x 127 x 33.6mm

Color

White

Warranty

Warranty Details

1 Year (Without Adapter)

Additional Info

Feature

Guest Network, IPTV, Signal Adjustment, PPPoE Username/password Clone, Smart WiFi Schedule, Smart Power Saving, Smart LED on/off, Tenda App, Dual-band in One, IPv6 Features Supported, Broadband management, MAC address clone, Backup & Restore configurations, Firmware upgrade from local.

Specialty

Designed for Medium-sized Apartment, Support Fiber Internet Up to 100Mbps, Tenda WiFi App provides the easiest way to manage AC5. Support Client Filter, Suppot IPTV, SSID Hiding Function, Support Guest Network, Support WPA2 for Safety.

Others

Wireless Standard: IEEE 802.11ac/a/n @5GHz, IEEE 802.11b/g/n @2.4GHz, Data Rate: 5GHz: Up to 867Mbps, 2.4GHz: Up to 300Mbps, Frequency: CE: 2.4G: 2412-2472MHz(CH1-CH13), 5G: 5150-5250MHz(CH36-CH64), FCC: 2.4G: 2412-2462MHz(CH1-CH11), 5G: 5150-5250MHz(CH36-CH64), 5725-5825MHz(CH149-CH165), Transmission Power: CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz), FCC: <30 dBm (2.4 GHz), <30 dBm (5 GHz), Wireless Security: WPA2-PSK, Wireless Security : Enable /Disable, Network Protocol: IPv4&IPv6, Parental Control: Client Filter, URL Filter, Time Limit, DHCP: DHCP Server, DHCP Client List, DHCP Static IP Address Reservation and Allocation, Virtual Server: Port Forwarding, DMZ Host, UPnP, Package Contents: Wi-Fi Router x1, RJ45 Ethernet Cablex1, Power Adapterx1, Quick Installation Guidex1. VPN: IPsec, PPTP, L2TP.

Certifications

CE, FCC, RoHS

Country Of Origin

China

Made in/ Assemble

China
